Relfar FWH30-D20C Laser Welding Head
Wavelength Range：1080nm
Weight:：1.0Kg
Rated Power：3KW
-
Trusted by over 1,000 customers worldwide
-
1–3 year extended warranty coverage
-
Certified to meet international quality standards
-
100% quality inspection before shipment
The FWH30-D20C laser welding head is an intelligent dual-pendulum handheld laser welding head designed for industrial welding applications. It offers extended focal length and a wider spot adjustment range, ideal for complex, high-quality seam welding over greater working distances.
| Parameter | Specification |
|---|---|
| Product Name | FWH30-D20C Laser Welding Head |
| Model | FWH30-D20C-V4-T |
| Fiber Interface | QBH |
| Wavelength Range | 1080nm |
| Rated Power | ≤3000W |
| Collimation Focal Length | 40mm |
| Focusing Focal Length | 200mm |
| Oscillation Type | —, ○, ∞, ◎, △ |
| Focal Point Adjustment Range | -10mm ~ +10mm |
| Spot Size Adjustment Range | 0 ~ 8mm |
| Auxiliary Air Pressure | ≤1MPa |
| Weight | 1.0Kg |
